PNEUMATSKI ČEKIĆI

AT29: Mechanical poker for the high frequency AME1500 system

Technical Specifications
Hammer type Chipping hammer
Hammer version Vibro-reduced
Tool retainer cap
Weight 6.5 kg
Length 450 mm
Air consumption 10 l/s
Impact Rate 2640 blows/min
Vibration level 3 axes (ISO 28927-10)* 2.4 m/s²
Sound power level guaranteed, Lw (2000/14/EC)** 105 dB(A)
Sound pressure level (ISO 11203)** Lp, r=1m 87 dB(A)
Shank Size (mm) Hex 19x50
Shank Size (inch) Hex 3/4x2

Za više informacija posetite sajt proizvođača

TEX 09PS: Pneumatic hammer (Hex 22x82,5) (7/8x3 1/4) with cap retainer

Technical Specifications
Hammer type Pick hammer
Hammer version Standard
Tool retainer cap
Weight 10 kg
Length 500 mm
Air consumption 18.5 l/s
Impact Rate 1800 blows/min
Vibration level 3 axes (ISO 28927-10)* 16.1 m/s²
Sound power level guaranteed, Lw (2000/14/EC)** 103 dB(A)
Sound pressure level (ISO 11203)** Lp, r=1m 91 dB(A)
Shank Size (mm) Hex 22x82,5
Shank Size (inch) Hex 7/8x3 1/4

Za više informacija posetite sajt proizvođača

TEX 12PE: Pneumatic hammer (Hex 22x82,5) (7/8x3 1/4) with latch retainer, including front side handle

Technical Specifications
Hammer type Pick hammer
Hammer version Vibro-reduced
Tool retainer kick-latch
Weight 12 kg
Length 590 mm
Air consumption 20 l/s
Impact Rate 1620 blows/min
Vibration level 3 axes (ISO 28927-10)* 4 m/s²
Sound power level guaranteed, Lw (2000/14/EC)** 105 dB(A)
Sound pressure level (ISO 11203)** Lp, r=1m 93 dB(A)
Shank Size (mm) Hex 22x82,5
Shank Size (inch) Hex 7/8x3 1/4

Za više informacija posetite sajt proizvođača

TEX 12PSR KL: Pneumatic hammer (Round 25x75) with kick-latch retainer

Technical Specifications
Hammer type Pick hammer
Hammer version Standard
Tool retainer kick-latch
Weight 12.5 kg
Length 545 mm
Air consumption 21.3 l/s
Impact Rate 1600 blows/min
Vibration level 3 axes (ISO 28927-10)* 15.4 m/s²
Sound power level guaranteed, Lw (2000/14/EC)** 105 dB(A)
Sound pressure level (ISO 11203)** Lp, r=1m 92 dB(A)
Shank Size (mm) Rd 25x75
Shank Size (inch) Rd 1x3

Za više informacija posetite sajt proizvođača
